PRODUCT DETAILS
Description
The HD Air MAXX PH 45K delivers true heavy-duty performance with a 45,000 lb GVWR and payload capacity up to 34,500 lbs. Built on a 14" @ 22 lb I-beam main frame with pierced crossmembers, it’s engineered for maximum strength and stability under serious loads. Standard equipment includes Hutch 9700 suspension with 49" axle spread, dual 22,500 lb oil bath axles, air brakes with ABS, and a 60,000 lb adjustable bolt-on pintle. Finished with 2" nominal oak decking, hydraulic wood-lined ramps, lifetime LED lighting, and dual 25K jacks — all backed by a 2-year structural frame warranty.
Trailer Town is a Buckeye Trailers dealer. Pick your deck length and the upgrades you need, then send us your build. Prices shown are Buckeye's minimum advertised price (MAP), FOB the Buckeye factory: freight, delivery, tax, tag and registration are extra.
Standard features
| Trailer | Heavy Duty Deck-Over Pintle Hook |
|---|---|
| GVWR | 45,000 lb |
| Payload | 34,500 lb |
| Empty Weight | Est 10,500 lb |
| Deck Length | 18’ Flat Deck + 6’ Wood-Lined dovetail |
| Deck Width | 102" |
| Deck Height | 36” Deck Height |
| Frame | 14” I-Beam Main Frame & Tongue (22 lb) with Pierced 4” Crosspieces on 16” Centers |
| Suspension | Hutch 9700 Suspension, 49” Axle Spread |
| Floor | 2” Nominal Oak Decking |
| Axles | 2 x 22,500 lb Heavy Wall Oil Bath Axles |
| Tires | 215/75R17.5 18-Ply Tires |
| Wheels | 17.5” Rims |
| Bolt Pattern | 8-Lug on 275 mm |
| Spare Mount | Undercarriage Spare Mount |
| Jacks | 2 Dual-Speed 25K Jacks |
| Brakes | Air Brakes on All Hubs, 2S/1M ABS, T3030 Air Chambers |
| Coupler | 60,000 lb Bolt-on, Adjustable Pintle |
| Tie Downs | Heavy-Duty D-Rings, every 2' On Each Side |
| Ramps | 6’ Tall x 30” Wide Hydraulic Ramps Wood Lined |
| Safety | DOT-Approved Reflective Tape |
| Trailer Plug | 7-Way Semi Plug for Signals & Lighting |
| Storage | Chain Box with a Lockable Lid |
| Lights | Lifetime LED Lights, Rubber Mounted |
| Finish | Automotive-Grade Epoxy Primer with Two Top Coats of Industrial Urethane |
| Warranty | 2 Year Structural Frame |
Not included: Runners, Breakaway Kit.
Specifications and pricing from Buckeye Trailers; subject to change without notice.
